Technical DataFree Sample
Please ask for free sample in order to check if the products meets your requirement for your application.
Send your delivery adress and your specific requirements.
| Type | Rated current | Rated Voltage [VAC] | Rated Voltage [VDC] | Amount | Part Number |
| OMF 63 | 100 mA | 63 | 63 | 5 pieces | 3402.004.11 |
| OMF 63 | 250 mA | 63 | 63 | 5 pieces | 3402.0006.11 |
| OMF 63 | 630 mA | 63 | 63 | 5 pieces | 3402.0008.11 |
| OMF 63 | 1 A | 63 | 63 | 5 pieces | 3402.0009.11 |
| OMF 63 | 1.6 A | 63 | 63 | 5 pieces | 3402.0011.11 |
| OMF 63 | 2 A | 63 | 63 | 5 pieces | 3402.0012.11 |
| OMF 63 | 3.5 A | 63 | 63 | 5 pieces | 3402.0015.11 |
| OMF 63 | 5 A | 63 | 63 | 5 pieces | 3402.0017.11 |
| OMH 125 | 5 pieces | 0031.7701.11 | |||
| OMF 250 | 500 mA | 250 | 250 | 10 pieces | 3403.0013.11 |
| OMF 250 | 800 mA | 250 | 250 | 10 pieces | 3403.0015.11 |
| OMF 250 | 1 A | 250 | 250 | 10 pieces | 3403.0016.11 |
| OMF 250 | 1.25 A | 250 | 250 | 10 pieces | 3403.0017.11 |
| OMF 250 | 1.6 A | 250 | 250 | 10 pieces | 3403.0018.11 |
| OMF 250 | 2 A | 250 | 250 | 10 pieces | 3403.0019.11 |
| OMF 250 | 250 | 250 | 10 pieces | 3403.0021.11 | |
| OMF 250 | 4 A | 250 | 250 | 10 pieces | 3403.0022.11 |
| OMF 125 | 100 mA | 125 | 125 | 5 pieces | 3404.0004.11 |
| OMF 125 | 250 mA | 125 | 125 | 5 pieces | 3404.0006.11 |
| OMF 125 | 630 mA | 125 | 125 | 5 pieces | 3404.0008.11 |
| OMF 125 | 1 A | 125 | 125 | 5 pieces | 3404.0009.11 |
| OMF 125 | 1.6 A | 125 | 125 | 5 pieces | 3404.0011.11 |
| OMF 125 | 2 A | 125 | 125 | 5 pieces | 3404.0012.11 |
| OMF 125 | 3.5 A | 125 | 125 | 5 pieces | 3404.0015.11 |
| OMF 125 | 5 A | 125 | 125 | 5 pieces | 3404.0017.11 |
Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in
Details about Approvals
SCHURTER products are designed for use in industrial environments. They have approvals from independent testing bodies according to national and international standards. Products with specific characteristics and requirements such as required in the automotive sector according to IATF 16949, medical technology according to ISO 13485 or in the aerospace industry can be offered exclusively with customer-specific, individual agreements by SCHURTER.
Compliances
The product complies with following Guide Lines
| Identification | Details | Initiator | Description |
|---|---|---|---|
|
SCHURTER AG | On 1 June 2007, Regulation (EC) No 1907/2006 on the Registration, Evaluation, Authorization and Restriction of Chemicals 1 (abbreviated as "REACH") entered into force. |
LOADING...
Short Table of Variants Fuse Kit OMF Open complete table Fuse Kit OMF
| Designation |
Order Number
|
Free Sample |
Distributor Stock Check Distributor Stock Check
|
... |
|---|---|---|---|---|
| Fuse Kit OMF 63/125/250 | 0034.9877 | - | ... |
01.10.2024
