Rated Current Ie
63 A @ 500 VAC
63 A@ 500 VAC
Rated voltage Ue
500 VAC
Rated isolation voltage Ui
1000 VAC
Rated Power Operating Frequency fe
50 Hz
Element with Double Straps
6 - 50 mm²
Rated Impulse Withstand Voltage Uimp
6 kV
Conditioned Rated Short Cicuit Current
20 kA @ 500 VAC
Rated short-time withstand current with fuse links
20 kA␠ @ 500 VAC
Allowed Ambient Temperature
-25 °C to +40 °C acc. to IEC 61439
Protection by closed housing
IP20
Neutral Disconnector with Straps
6 - 50 mm²
Earth Connection Bride
6 - 50 mm²
Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in Details about Approvals
The product complies with following Guide Lines
| Identification | Details | Initiator | Description |
|---|---|---|---|
|
SCHURTER AG | On 1 June 2007, Regulation (EC) No 1907/2006 on the Registration, Evaluation, Authorization and Restriction of Chemicals 1 (abbreviated as "REACH") entered into force. |
| Designation | Terminal |
Order Number
Variant Details
|
E-No. | A=Most Popular A=Most Popular
|
Free Sample Free Sample
|
Distributor Stock Check Distributor Stock Check
|
... | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 63A DIII+0 | Straps | 0009.9103 | - | A | ... | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
█ Most Popular. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packaging unit | 1 Pcs |
